Description
| Feature | Description |
|---|---|
| Series | MP28 Series |
| Product Type | Low ESR Aluminum Electrolytic Capacitor |
| Capacitance Range | 6.8µF to 680µF |
| Rated Voltage Range | 2V to 25V DC |
| Temperature Range | -55°C to +105°C |
| Endurance | 2,000 Hours at 105°C |
| Compliance | RoHS Compliant and Lead-Free |
Technical Specifications
| Specification | Value |
|---|---|
| Series | MP28 Series |
| Product Type | Low ESR Aluminum Electrolytic Capacitor |
| Temperature Range | -55°C to +105°C |
| Rated Voltage Range | 2V to 25V DC |
| Nominal Capacitance Range | 6.8µF to 680µF |
| Capacitance Tolerance | ±20% (Standard) |
| DC Leakage Current | Specified by capacitance and rated voltage; measured at 20°C after 2 minutes |
| Dissipation Factor (tanδ) | 0.06 to 0.08 maximum, depending on rated voltage |
| Test Frequency | 120Hz at 20°C for capacitance and dissipation factor measurements |
| ESR | Low ESR; specified at 100kHz and 20°C |
| Endurance | 2,000 Hours at 105°C |
| Compliance | RoHS Compliant and Lead-Free |
Performance Advantages
| Advantage | Benefit |
|---|---|
| Low ESR Performance | Helps reduce equivalent series resistance and supports efficient operation in compact electronic circuits. |
| Wide Temperature Range | Designed for dependable operation across a -55°C to +105°C temperature range. |
| 2,000-Hour Endurance | Provides reliable long-term operation when used within specified operating conditions. |
| Broad Capacitance Range | Available from 6.8µF to 680µF for flexible circuit design and replacement requirements. |
| Compact Electronics Support | Suitable for compact electronic equipment requiring reliable filtering and energy storage. |
| RoHS & Lead-Free | Supports environmentally conscious electronic product designs and manufacturing requirements. |
Applications
| Application | Typical Usage |
|---|---|
| System Boards | Power filtering and voltage stabilization for system board and electronic circuit applications. |
| Display Cards | Used for filtering and energy storage in display card and related electronic circuits. |
| Small Chargers | Suitable for compact charger circuits requiring dependable low ESR capacitor performance. |
| Intelligent TVs | Designed for power filtering and circuit stabilization in intelligent TV electronic systems. |
| Consumer Electronics | Applicable to compact electronic equipment requiring aluminum electrolytic capacitors with low ESR characteristics. |
Why Choose MP28 Series
The MP28 Series is a low ESR aluminum electrolytic capacitor series designed for compact electronic applications that require stable electrical performance, dependable filtering and reliable energy storage. With a capacitance range from 6.8µF to 680µF and rated voltage options from 2V to 25V DC, the series provides flexible solutions for a wide range of electronic circuit designs.
Engineered for operation from -55°C to +105°C, MP28 Series capacitors provide reliable performance across a broad temperature range. The 2,000-hour endurance rating at 105°C makes the series suitable for system boards, display cards, small chargers and intelligent TV applications.
With low ESR characteristics, RoHS compliance and lead-free construction, the MP28 Series is a practical choice for manufacturers, engineers and electronic repair professionals seeking dependable aluminum electrolytic capacitors for modern electronic equipment.
Quality Assurance
MP28 Series capacitors are designed according to defined electrical and endurance characteristics to provide consistent performance in their intended applications. Key characteristics include capacitance, rated voltage, leakage current, dissipation factor, ESR and endurance performance.
The series is RoHS compliant and lead-free, making it suitable for electronic manufacturers and professional applications where reliable component performance and environmental compliance are important requirements.
Product Summary
| Category | Information |
|---|---|
| Series | MP28 Series |
| Product | MP28 Series Low ESR Aluminum Electrolytic Capacitor |
| Capacitance Range | 6.8µF to 680µF |
| Rated Voltage Range | 2V to 25V DC |
| Endurance | 2,000 Hours at 105°C |
| Temperature Range | -55°C to +105°C |
| Recommended Applications | System Boards, Display Cards, Small Chargers and Intelligent TVs |
| Compliance | RoHS Compliant and Lead-Free |
The MP28 Series is a low ESR aluminum electrolytic capacitor series engineered for reliable electrical performance in compact electronic equipment. With a broad capacitance range, multiple voltage ratings and a wide operating temperature range, it provides flexible solutions for system boards, display cards, small chargers and intelligent TV applications.
Featuring 2,000-hour endurance at 105°C, RoHS compliance and lead-free construction, MP28 Series capacitors are designed to meet the needs of modern electronic manufacturing, component replacement and professional circuit applications.
MP28 Series • Low ESR • RoHS Compliant • Lead-Free
